Electronics Industry - Product Spotlight

Noisecom
NC1101A
Amplified Noise Module

The NC1000 Series amplified noise modules produce AWGN as high as +13 dBm, and have bandwidths up to 10 GHz. The high power modules are designed to test noise immunity for Cable TV equipment, secure communication channels, and military jamming systems. The lower power modules, <= 0 dBm, are random jitter sources for many applications including, PCIexpress, Infiniband, and 10 GigE. The Bandwidth, output power, and flatness can be modified for specific applications. A newly developed TTL controlled attenuation feature is also available.

Applications

  • 10 GbE
  • IEEE 802.3
  • Infiniband
  • PCIexpress
  • CATV
  • Jamming systems

Specifications

High power Up to +13 dBm

Standard input Voltage +28VDC (below 1.5 GHz) +15 VDC (above 1.5 GHz)

Operating temperature -35° to +100°C

Storage temperature -65° to +150°C

Typical temperature coefficient 0.025 dB/°C

Supply voltage sensitivity 0.25 dB/1%?V

Output connector SMA female connector (BNC available as option)

Options

NC1opt01 +15 VDC

NC1opt02 +24 VDC

NC1opt03 BNC female connector (NC1101A through NC1110 only)

NC1opt04 0 dBm output (Package 2, NC1101A through NC1110A) Not available for NC1124, NC1126 & NC1128

NC1opt05 TTL control “High” is on (add “T”)

NC1opt06 TTL control “Low” is on (add “IT”)

NC1opt07 Special frequency range (consult factory)NC1opt08 Package 3, NC1110A only (add “P3”)NC1opt09 +12VDC (Not Available on NC1120A)
